* Disable Push Pull Deadlatch Paddle Handle
* Deadlatch Paddle
* For aluminum doors
* Compatible with model #003, #005 deadlatch lock
* Zinc die cast housing black finish
* Extruded aluminium paddle in aluminum finish
* Reversible gear block
* Either right or left hand for push or pull operation available
* Size: 45x33x103mm
* Available in 4 modes, Pull to left, Push to left, Pull to right, Push to right
* Finished of Paddle : Extruded aluminum, Anodized finish, Dark Bronze Anodized Black Anodized available
* Cam plug : Secured in latch body by cylinder setscrew, plug is also tied to escutcheon by hardened steel pins
Operation
| Use
|
Pull to Left
| Outside of left hand reverse door or inside of right hand.
|
Push to Left
| Outside of left hand door or inside of right hand reverse.
|
Pull to Right
| Outside of right hand reverse door or inside of left hand.
|
Push to Right
| Outside of right hand door or inside of left hand reverse.
|
